From real racing to sim racing

Venym works closely with Mygale, allowing us to have the best engineers in real-life motorsports working on products for racing simulators. Analysis, design, and calculation are the key elements of our expertise. We've characterized everything that can happen in real life to translate it into sim racing and make it accessible to all virtual drivers.

The ultimate sensations at an affordable price

Our sim racing pedals use full load cells to translate mechanical forces into electronic information.

• 2 load cells of 1 kg for the throttle and clutch
• 1 load cell of 200kg on the brake.

In terms of mechanical feel, the effort is translated by a spring for the throttle, a spring plus special kinematics so that sim racers feel the same sensation as in real life with the clutch.

For the brake, the most relevant choice was rubber that offers real precision in pedal pressure while giving a sensation of significant effort, just like on a track.

French Industry

Our sim racing pedals are designed and assembled by a team of car enthusiasts at the Nevers-Magny-Cours circuit, the heart of French motorsport. Our Venym sim racing pedals are the first pedals designed in France, inspired by the design and technologies used in F1 cockpits.

Custom electronics

Our sim racing pedals are equipped with a dedicated ADC (analogue-digital converter) chip that allows us to sample 20 bits per pedal. This is coupled with a 48MHz microcontroller, providing computing power that allows us to process the signal and interpolate the response curves using floating-point numbers. All of this is done in near real time, with a 1ms response time, where competitors only offer linear interpolation in integers.

Internally developed software

The firmware and the "Pitstop" app (Windows 10) are also developed in-house. This allows us to be very responsive in fixing bugs and, above all, in implementing new features (numerous and frequent updates).

Machined aluminum and "V" design

Monobloc aluminum casting. High strength and durability.
Formula 1-inspired design. Fully customizable with a wide variety of colors available.

Up to 200kg of pressing force, more than necessary in a formula (130kg).

Full load cell

Adjustable braking force from 60 to 130 kg makes your brakes instantly faster thanks to 1 ms sampling.

Born to compete

Backed by Mygale and his 30 years of experience in motorsports.

Custom and specific software

Our software allows you to configure your pedals exactly the way you want.

What is included?

• A Venym pedal set
• Our base set of rubber and springs. Tested and approved by some of the world's best sim racers. Our kit has been validated to provide the best experience in terms of feel.
• Contains a pair of green rubbers (braking force of 100 kg) and a pair of green springs
• A dedicated simulation software
• Mounting tools
• Venym decals for your sim rig and our quick start guide
